Seamless Stainless Steel TP347 |UNS S34700|1.4550 Tube
Distinguished by the strategic addition of Niobium (Columbium), our TP347 tubing prevents chromium carbide precipitation during prolonged exposure to temperatures in the 427°C - 816°C (800°F - 1500°F) range. This makes them indispensable for mission-critical applications in chemical reactors, high-pressure steam systems, and aerospace components. Through advanced cold-drawing and precise solution annealing, Tengqi ensures every tube maintains a uniform microstructure and optimized mechanical strength for demanding industrial media.
"While TP347 provides excellent corrosion resistance, we also offer TP347H (UNS S34709) with higher carbon content for superior creep strength in temperatures above 1000°F."
Seamless Stainless Steel TP347 Tube (TP347 / UNS S34700 / W.Nr. 1.4550) is a niobium-stabilized austenitic grade for high-temperature and nuclear-grade service. Manufactured by Tengqi in Fujian, China, every heat is fully traceable, hydro-tested and available with third-party inspection (SGS / BV / TUV) on request.
Product Specifications
- ASTM A213 / ASME SA213 — Seamless
- ASTM A269 / A269M — Seamless & Welded
- ASTM A270 / A270M — Sanitary Tubing
- ASTM A1016 / A1016M — General Requirements
- EN 10216-5 — Seamless Pressure Tubing
- Finishing: solution annealed, pickled & polished; bright annealed available on request
Size Range
| Outside Diameter (OD) | Wall Thickness | Length |
|---|---|---|
| 6.35 mm – 257 mm (1/4"– 10.1") | 0.5 mm – 12.7 mm | ≤ 22 m |
Chemical Composition
TP347 (UNS S34700) — Composition %
| UNS | C | Mn | P | S | Si | Cr | Ni | Nb |
|---|---|---|---|---|---|---|---|---|
| S34700 | ≤ 0.08 | ≤ 2.00 | ≤ 0.045 | ≤ 0.030 | ≤ 1.00 | 17.0 – 20.0 | 9.0 – 13.0 | 10xC-1.10 |
Mechanical Properties
| Property | Value |
|---|---|
| Delivery Condition | Solution annealed, pickled & polished |
| Tensile Strength | ≥ 515 MPa |
| Yield Strength (0.2% offset) | ≥ 205 MPa |
| Elongation in 2 in. / 50 mm | ≥ 35% |
Physical Properties
| Property | Value |
|---|---|
| Density | 7.9 g/cm3 |
| Thermal Conductivity | 16.1 W/m·K |
| Specific Heat Capacity | 500 J/kg·K |
| Elastic Modulus | 193 GPa |
| Magnetic Properties | Non-magnetic (slightly magnetic when cold worked) |
| PREN (Pitting Resistance Equivalent) | 18.0-20.0 |
Industry Applications
